Features and Benefits

Built-in pallet base (not detachable) for easy and safe handling.



Stacking when full up to 4 x Multitank (2.000 kg maximum weight).



Nesting when empty, reducing storage space.



3 x different sizes of waterproof and airtight lids for easy filling and emptying,

• Solids,

• Liquids & pulps

• Products preserved in liquid environment (brine)



2’’ inch bottom discharge hole with BSP thread



One way valve, to release internal gases.



RFI tag, 4 x label places



Technical Specifications

External Dimension Including Lid:

Top: 1 000 x 800 x 958 mm

Bottom: 800 x 600 mm



External Dimension Excluding Lid:

Top: 1 000 x 800 x 935 mm



Internal Dimension Excluding Lid:

Top: 963 x 763 x 778 mm



Stack Height:

Dynamic: 2 x Multitank 1 847 mm

Static: 4 x Multitank 3 800 mm



Nest Height:

Body: 11 x Bodies 2 490 mm

Lids: 36 x Lids 2 540 mm



Volume:

Nominal Volume: 400 litres

Working Volume: 385 litres



Working Temperature:

- 40°C / + 40°C



Static Loading:

1 x Multitank 500 kg

4 x Multitank* 2 000 kg



Dynamic Loading:

2 x Multitank 1000 kg



Loading on a truck:

Full: 79 units

Empty: 320 units



Loading on a 40 foot container:

Full: 72 units

Empty: 300 units
